Capacitance Level Transmitter
w/ 4-20 mA Output
The Intempco LTX20-C1 capacitance fuel level transmitter is designed to measure level of fuels and oils in metallic and non-metallic tanks. The probe measures level by measuring the change in capacitance as level changes in the tank. The micro-processor based electronics converts this capacitance change into a linear, highly accurate 4-20mA signal.
The LTX20-C1 includes a standard 4-20mA loop powered LTX transmitter mounted in an explosion proof head, fitting and a concentric probe for measuring ranges of up to 10 feet. Probe material is SS316. The LTX20 is designed for tanks which have fitting connections of 3/4” NPT or larger.
An excellent application for the LTX20-C1 are stationary or mobile generators. This level sensor is shock resistant and very rugged. There are no moving parts. To isolate for ground loops, a non-conductive reducer (such as PVC) can be used between the tank and the 3/4” NPT process connection.
LTX20 EX Fuel/Oil Details
