RTD Temperature Transmitter w/Surface Mount Pad
Temperature / Surface Mount Temperature Sensors / MIST M340

RTD Temperature Transmitter w/Surface Mount Pad Picture
  • Output signals: 4-20mA 2-wire; 0-5, 1-5, 0-10 VDC 3-wire
  • Input: Platinum RTD 100, Class A, 3-wire
  • Ranges: Std. and programmable from -50°C to 200°C
  • Power Supply: 10-32 VDC polarity protected
  • Accuracy: ±(.10°C + 0.10% of calibrated span ) with two-point calibration
  • Wetted Mat'l: SS316/316L, dual certified
  • Housing: Mat'l: SS316
  • Electrical Connection: M12 male receptacle
  • Operating Temp. Range: -40°C to 80°C (housing only)
  • Protection: Meets NEMA 6P, IP67 (IEC 529)

The MIST M340 RTD Temperature Transmitter consists of surface mount ring type RTD, extension cable to remote transmitter and M12 connector. It is designed for heavy duty BTU temperature measurement applications due to its very high accuracy. As all the other MIST Series transducers, it can be re-calibrated and re-scaled in the field.

RTD Temperature Transmitter w/Surface Mount Pad Details

  • Model Number

  • 1
    Calibrated Temperature Range

  • 2
    Output

  • 3
    Pad Hole Diameter 'D'

  • 4
    Pad Material

  • 5
    Pad Size

  • 6
    Pad Radius “r”

  • 7
    Extension Cable Type “E”

  • 8
    Extension Cable Type and Length 'E'
      From 01 to 99 feet
  • 9
    Connector Type

  • 10
    Extension Cable Length “H”


  • Comments / Specifications
